| Size[mm] | Weight [g] | EAN-code (4952269) |
|||||
| Overall length | Head width | Head thickness | Handle width | Edge length | |||
| PN-125 | 135 | 17 | 8 | 51 | 19 | 90 | 107012 |
| PN-150 | 162 | 19 | 8 | 49 | 21 | 110 | 107029 |
| PN-175 | 190 | 22 | 11 | 52 | 24 | 220 | 107036 |
| Cutting capacity (φmm) | Plastic | Copper | Stranded copper wire [mm²] |
| PN-125 | 5.0 | - | - |
| PN-150 | 5.0 | - | - |
| PN-175 | 6.0 | 2.0 | 5.5 |
Note: Do not use to cut harder wire or anything above it rated the capacity.
